Tiếng ViệtPretreatment for Automotive Bumper Cathodic Electrophoretic Coating
ST-P2320
Price: USD5000~10000
Get Quote PDF
A fully spray-based treatment process is adopted to make efficient use of the production space.
Multi-stage counterflow rinsing is used after degreasing and ceramic conversion coating, which improves cleaning quality while saving water.
The spray riser pipes are equipped with a two-stage pressure regulation system, ensuring more stable output from the atomizing nozzles.
Quick-connect fittings are used between the spray riser pipes and the main pipelines, allowing easy installation and maintenance.
Pretreatment Equipment and Pure Water System
The pretreatment equipment consists of 8 process stages, 8 spray systems, 8 spray solution storage tanks, 8 spray circulation pumps, and 3 heating systems.
Main equipment configuration:
1. Spray booth: 1 line
2. Spray piping systems: 8 sets
3. Spray solution storage tanks: 8 units
4. Spray pumps: 8 units
5. Exhaust systems: 2 units; inspection doors and platforms: 1 set; inlet and outlet stairways: 2 sets
6. Heating systems: 3 sets; stainless steel heat exchangers: 3 units; natural gas burners: 3 units
7. Main water supply pipelines: 2 sets; branch water supply pipelines: 8 sets
Coating solutions for Industry
Pretreatment for Automotive Bumper Cathodic Electrophoretic Coating Line
1. Hot Water Washing Section: 1 unit
Basic requirements:
The booth body is made of 304 matte-finished stainless steel sheet; the tank uses 304 stainless steel as the inner plate with 50 mm insulation; the frame is constructed from 50 × 3 square tubing; the outer panel is δ0.8 stainless steel sheet; plug-in panel structure.
2. Pre-degreasing Section: 1 unit
Basic requirements:
The booth body is made of 304 matte-finished stainless steel sheet; the tank uses 304 stainless steel as the inner plate with 50 mm insulation; the frame is constructed from 50 × 3 square tubing; the outer panel is δ0.8 stainless steel sheet; plug-in panel structure.
3. Main Degreasing Section: 1 unit
Basic requirements:
The booth body is made of 304 matte-finished stainless steel sheet; the tank uses 304 stainless steel as the inner plate with 50 mm insulation; the frame is constructed from 50 × 3 square tubing; the outer panel is δ0.8 stainless steel sheet; plug-in panel structure.
4. Water Rinse Section 1: 1 unit
Basic requirements:
The booth body is made of SUS304 stainless steel sheet; the tank is fabricated from single-layer 304 stainless steel sheet; leg height: 100 mm.
5. Water Rinse Section 2: 1 unit
Basic requirements:
The booth body is made of SUS304 stainless steel sheet; the tank is fabricated from single-layer 304 stainless steel sheet; leg height: 100 mm.
6. Ceramic Conversion Coating Section: 1 unit
Basic requirements:
The booth body is made of SUS304 stainless steel sheet; the tank is fabricated from single-layer 304 stainless steel sheet; leg height: 100 mm.
7. Water Rinse Section 3: 1 unit
Basic requirements:
The booth body is made of SUS304 stainless steel sheet; the tank is fabricated from single-layer 304 stainless steel sheet; leg height: 100 mm.
