Tiếng ViệtPhosphate Pretreatment for Powder Coating
ST-P5144
Price: USD1000~1500
Get Quote PDF
Design Philosophy: Highly flexible systems with space-saving layouts and low operating expenditure, planned from the outset.
Optimization Approach: Cross-process strategies to unlock potential in energy consumption and coating quality.
Resource Efficiency: Continuous filtration of process liquids to reduce chemical and water consumption.
Proven Technologies: Examples include the rotational dip process and the optimized anode control system.
From washing and surface conditioning to final sealing, there are numerous methods available to pretreat a substrate before coating. Each step comes with its own advantages and limitations. The purpose of pretreatment is to ensure the surface can properly receive the coating, maintain its quality for the longest possible time, and protect it against corrosion—while also removing contaminants such as grease, grime, and insect residue. These procedures and dwell times exist for good reason; skipping or shortening them will quickly lead to unsatisfactory outcomes.
No | Equipment Description | Specifications | Quantity |
一 | Spray Pre-Treatment System Dimension | L52500×W1800×H4400+700（mm） | 1 set |
(1) | Pre-Cleaning Dimension | L6000×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L6000 × W1800 × H4400 mm; Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head; 23m³/h; 3kW | 1 pc |
6 | Solution tank | L800×W2400×H700 mm; SS304: tank δ2.5mm; cover δ1.2mm; 10-mesh SS304 | 1 pc |
7 | Chamber rail support | L6000×W1200×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L6000×W1200×H700（mm） 100×100 square tube δ2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
(2) | Main Degreasing Section | L10500×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L10500×W1800×H4400（mm） Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head;75.2m³/h flow; 7.5kW | 1 pc |
6 | Solution tank | L2000 × W2400 × H700 mm | 1pc |
7 | Chamber rail support | L10500×W1800×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L10500×W1800×H700（mm） 100×100 square tube δ2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
No | Equipment Description | Specifications | Quantity |
(3) | Water Rinse Section 1 | L8500×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L8500×W1800×H4400（mm） Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head,23m3/h flow, 3KW | 1 pc |
6 | Solution tank | L800×W2400×H700（mm） SS304: tank δ2.5mm; cover δ1.2mm; 10-mesh SS304 | 1 pc |
7 | Chamber rail support | L8500×W1800×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L8500×W1800×H700（mm） 100×100 square tubeδ2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
(4) | Water Rinse Section 2 | L6500×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L6500×W1800×H4400（mm） Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head,23m3/h flow, 3KW | 1 pc |
6 | Solution tank | L800×W2400×H700（mm） SS304: tank δ2.5mm; cover δ1.2mm; 10-mesh SS304 | 1 pc |
7 | Chamber rail support | L6500×W1800×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L6500×W1800×H700（mm） 100×100 square tubeδ2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
No | Equipment Description | Specifications | Quantity |
(5) | Chromating | L11500×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L11500×W1800×H4400（mm） Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head：75.2m3/h flow,7.5KW | 1 pc |
6 | Solution tank | L2000×W2400×H700（mm） SS304: tank δ2.5mm; cover δ1.2mm; 10-mesh SS304 | 1 pc |
7 | Chamber rail support | L11500×W1800×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L11500×W1800×H700（mm） 100×100 square tubeδ2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
(6) | Pure Water Rinse Section | L9500×W1800×H4400+700（mm） | 1 set |
1 | Spray chamber | L9500×W1800×H3100（mm） Stainless steel 304: side/top δ1.5mm, bottom δ2.0mm | 1 set |
2 | Transition baffle | Stainless steel 304 δ1.2mm | 1 set |
3 | Nozzles | PP board | Included |
4 | Circulation pipeline | PPR material | Included |
5 | Circulation pump | KD-65VK-155NF-IF-OC-OB;20m head,23m3/h flow, 3KW | 1 pc |
6 | Solution tank | L800×W2400×H700（mm） SS304: tank δ2.5mm; cover δ1.2mm; 10-mesh SS304 | 1 pc |
7 | Chamber rail support | L9500×W1800×600（mm） 40×80 square tube δ2.0mm | 1 set |
8 | Chamber support frame | L9500×W1800×H700（mm） 100×100δsquare tube 2.0mm | 1 set |
9 | Water/heating fittings | Valves, pressure gauge, overflow pipe, tees, plugs, etc. | Included |
(7) | Drip Tray | L7000×W400×H200（mm） Stainless steel 304 δ1.2mm | 1 set |
