Tiếng ViệtAutomatic Spray Painting Booth
ST-APC-B2021
Price: USD1000~1500
Get Quote PDF
Automation in Manufacturing: Enhances competitiveness and efficiency; Requires careful evaluation before investment
Cost Considerations: High initial automation costs may not suit small-scale or low-volume production; Economic feasibility depends on production quantity and scale
Ideal Applications: High-volume production parts; Labor-intensive processes; Parts with similar shapes or configurations; Reduced costs for fixtures and spray path programming
Technology & Flexibility: Modern industrial automation offers greater flexibility than earlier systems
To begin with, automated spray booths greatly enhance painting efficiency. Their accurate application control reduces overspray and material waste, helping to cut overall operating costs. Moreover, the uniform coating achieved with ShengTai Equipment guarantees consistently high-quality finishes across all products.
Coating solutions for Industry
When striving for maximum efficiency in automated spray booth operations, ShengTai paint series robots stand out as a superior solution. Equipped with cutting-edge technology, they deliver fast, accurate coating application that ensures consistent quality results. Designed to accommodate intricate geometries and varying workpiece dimensions, these booths integrate smoothly into diverse production environments and adapt effortlessly to your manufacturing needs.
| No | Specification Model | Quantity | Amount | Remarks |
| 1 | Spray Booth 2000*2100*2500 | 1 set | ||
| Galvanized Sheet | 1 batch | Galvanized 1.2mm spray coating | ||
| Recovery Machine 2000*600*2500 | 2 sets | Galvanized 1.2mm spray coating | ||
| Filter Element φ*325*900 | 4 sets | Chuck type | ||
| Air Tankφ160*2000 | 2 sets | 1-inch solenoid valve | ||
| Lifting Work | 1 set | With lifting function | ||
| Lighting | 4 sets | Explosion-proof LED | ||
| Control | 1 set | Delixi | ||
| 2 | Spray Equipment | 1 set | ||
| Manual Gun (Extended Barrel) (Unit Price 0.66) | 1 unit | Dber V11 | ||
| 3 | Curing Chamber 6000*2700*2900 | 1 set | ||
| Wall Panel 120mm (120 kg) | 80 m² | Outer 0.6, inner 0.6, pressed | ||
| Slot Box Corners Inside | 1 batch | 1.2mm spray coating | ||
| Doors | 2 batch | Both ends | ||
| 4 | Ground Rail | 1 set | ||
| 8 kg | 42 meter | |||
| Trolley 5500*2200*300 | 1 unit | 50*50 square tube 6 Wheels |
