Automatic Reciprocator for Powder Coating

ST-PCL-R200C

Price: USD1000-1500

Servo Precision Control – Servo motor with PLC touchscreen for accurate and stable spraying.
Multi-Gun Flexibility – Supports 1–2 spray guns with adjustable spray modes.
Five-Axis Reciprocator – Programmable motion for efficient and uniform coating.
Wide Paint Compatibility – Suitable for PU, PE, UV, and water-based paints.

The operation of a reciprocating spraying machine resembles a meticulously choreographed dance. Driven by a motor, the spray gun moves back and forth along a specific track. This track can be programmed as needed, allowing the gun to uniformly spray coating material throughout its motion. It acts like a precise painter, applying color stroke by stroke onto the object's surface.


Category	Attribute	Specification
General	Product Name	Automatic Powder Coating Reciprocator and Spray Gun
General	Model	ST-PCL-R200C
General	Origin	Shandong, China
Power & Drive	Power Supply	220V, Single Phase
	Rated Power	1.2 kW
	Total Power	5.0 kW
	Motor Type	Servo Motor
	Servo Drive Power	1.2 kW
Control System	Control Method	Touch Screen Control
	PLC Controller	Japan Omron
	Touchscreen	Taiwan Weintek
	Servo Motor Brand	Taiwan Delta
	Frequency Converter	Taiwan Delta
Mechanical Parameters	Travel	2 m (Customizable)
	Lowest Position	0.7 m
	Total Height	3.2 m
	Effective Processing Width	600 mm
	Effective Processing Length	600 mm
	External Dimensions	2200 × 1900 × 1500 mm
	Machine Weight	500 kg
Spraying System	Spray Gun Brand	Anest Iwata (Japan)
	Number of Spray Guns	1–2
	Nozzle Diameter	1.0 mm
	Paint Types	PU, PE, UV, Water-based Paint
	Oil Supply Method	Diaphragm Pump
	Air Pressure	0.4–0.6 MPa
Functional Advantages	Axis Type	Five-Axis Reciprocating System
	Recipe Storage	Up to 120 Sets
	Spraying Accuracy	Up to 1 mm
	Spray Modes	Multiple Modes with Contour Tracking
	Operation	PLC Touchscreen, Easy Operation
