I

Powder Coating Oven

1

set

1

External Dimensions L3440 × W1890 × H1940 mm

1

Set

2

Heating Method: Electric Heating

1

Set

3

Furnace Interior Dimensions: L3200 × W1650 × H1700 mm

1

Set

4

Furnace Body Structure: Single Door

1

Set

5

Furnace Shell Frame: 1.5mm Cold Plate Bending Fabrication

1

Set

6

Insulation Material: Aluminum Silicate Needled Blanket

1

Set

7

Oven Outer Panel: 1.2mm Cold Plate Bending Fabrication

1

Set

8

Oven Inner Panel: Galvanized Steel Plate Thickness 2.0mm or 1.2mm 201 Stainless Steel Plate

1

Set

9

Heating Tube: Adopts Blower Heating Tube

1

Unit

10

Heating Power: 24kW, 3kW/Piece

8

Piece

11

Temperature Control: Ambient Temp - 250℃

1

Set

12

Temperature Controller: Uses RKC-700 Type Temperature   Controller for Temperature Control

1

Piece

13

Temperature Measuring Element: Taiwan-made Imported CA Sensing Needle, Temperature Measurement Accuracy ±1%

1

Set

14

Exhaust Port: Natural Exhaust Port

1

Set

15

Primary Lifting Tool

1

Set

16

Electric Control System: Button Control

1

Set

17

Control Electrical Appliances: Chint or Delixi Brand Appliances

1

Batch

18

Power Line: 4~6mm² Power Cable

1

Batch

19

Control Line: 1.0~1.5mm² Electric Wire

1

Batch

20

Overload Protection: Overload Control for Each Motor

1

Set

21

Operation Display: Conveyor Operation Status Display

1

Set

22

Over-temperature Protection: Shutdown After Over-temperature

1

Set
